In this episode we'll making wing mounting, tail section and stabilizers. The tail section and stabilizers construction are pretty straight forward and all made out of foam sheet, no need for hard spars. Only the vertical stabilizer that needs a small plywood part. The plane so far is very light weight, just like I expected. The one that I have not expected is that, I thought the tail will be tilted downward because of its weight, but it isn't, so that's a good thing.
Specs :
1. Wingspan 1800mm / 71 inches
2. Flying weight : target below 2000 grams/ 70.5 oz
3. Wing loading : -
4. Wing cube loading : -
5. Wing Area : -
6. CG : -
7. 1 set of Servoless Retractable Landing Gear
Electronics
- 2X Turnigy 2826 2200kv brushless motor
- 2X ESC 40A
- Battery Lipo 2X 3S 2200 - 3S 5200mah - 2X Li-ion 3S 3300 mah
- 3 plastic gear 9 gram servos
- 3 metal gear 9 gram servos
- Propeller : 7x5 APC
Materials :
1. 5mm & 10mm Depron/ Polyfoam
2. 3mm Plywood
4. 0.3mm Mica Plastic
5. hot glue + CA glue + UHU glue
6. white packing tape
Open the PDF file with Adobe Acrobat Reader (recommended software)
PDF security password : none
RC Airliner Boeing 737-300 Part 3 plans
Build Video Tutorial on Youtube Part 3
